SPECIFICATION :
Frame
Spark 3 Carbon / IMP technology / HMX
BB92 / Carbon SMC Link / Carbon swingarm
SW DM dropouts for Boost 148x12mm
TBC Trunnion box construction
Fork
FOX 34 Float Factory Air / Kashima
FIT4 3-Modes with low speed adj. / 15x110mm QR axle
Tapered steerer / Reb. Adj. / Lockout / 120mm travel
Rear Shock
FOX NUDE Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout - Traction Control -Descend
DPS / EVOL / Kashima / Reb. Adj.
Travel 120 - 85 - Lockout / 165X45mm
Remote System
SCOTT TwinLoc Remote Technology
3 modes front and rear / integ. Grip clam
Headset
Syncros FL1.5 Drop in / Tapered 1.5" - 1 1/8"
Ti bearing diameter size 42mm and 52mm
Rear Derailleur
Shimano XTR RD-M9000 SGS
DM / Shadow Plus / 22 Speed
Front Derailleur
Shimano XTR FD-M9020-D / side swing
Shifters
Shimano XTR SL-M9000-I / Rapidfire Plus
2 way release / Ispec 2 clamp
Brakes
Shimano XTR M9000 Disc
180mm F & R / SM-RT99 CL Icetech Rotor
Crankset
Shimano XTR FC-M9020-B2 / Hollowtech 2
700 Series: 36x26 T / 900 Series: 34x24 T
BB-SET
Shimano SM-BB9441A / shell 41x92mm
Handlebar
Syncros FL1.0 SL Carbon T-Bar
T shape flat / 9° / 740mm
Syncros Pro lock-on grips
Handlebar Stem
Syncros FL1.5 / Alloy 2014
Integrated Spacer & Top Cup / 31.8mm / 6° / 1 1/8"
Garmin mount
Seatpost
FOX Transfer Dropper Remote
Kashima / 31.6mm / S size 100mm / M, L & XL 125mm
Seat
Syncros XR1.5 / Titanium rails
Hub (Front)
Syncros XR1.5 CL / 15x110mm
Made by DT Swiss
Hub (Rear)
Syncros XR1.5 CL / Boost 148x12mm
RWS w/removable Lever / 36T Rachet System / XD
Made by DT Swiss
Chain
Shimano CN-M901-11
Cassette
Shimano XTR CS-M9001 / 11-40 T
Spokes
DT Swiss Aero Comp
Rims
Syncros XR1.5 / 28H / Tubeless ready
Tires
Maxxis Forekaster / 2.35 / 120TPI Kevlar Bead
TR Tubeless Ready / EXO / 3C maxx speed
